| Model | Power | Dead weight | Total lifting weight | capacity | Maximum working pressure | Closing time | overall dimensions(mm) | ||||||
| 380V50Hz | 440V60Hz | 380V50Hz | 440V60Hz | A | B | C | D | E | |||||
| GBM15.0-3000 | 15 | 18 | 2870 | 5.3 | 3 | 180 | 11 | 9 | 2650 | 2440 | 2020 | 2750 | 2300 |
| GBM15.0-4000 | 3020 | 6.3 | 4 | 180 | 13 | 11 | 2800 | 2570 | 2140 | 2880 | 2300 | ||
| GBM18.5-5000 | 18.5 | 22 | 3670 | 7.7 | 5 | 180 | 13 | 11 | 2980 | 2740 | 2300 | 3080 | 2500 |
| GBM18.5-6000 | 3980 | 8.8 | 6 | 180 | 18 | 15 | 3100 | 2780 | 2470 | 3260 | 2500 | ||
| GBM22.0-7000 | 22 | 26 | 4720 | 10.4 | 7 | 180 | 18 | 15 | 3190 | 2880 | 2540 | 3340 | 2700 |
| GBM22.0-8000 | 5460 | 11.9 | 8 | 200 | 18 | 15 | 3660 | 3030 | 2620 | 3460 | 2900 | ||
| GBM30.0-9000 | 30 | 35 | 6740 | 14 | 9 | 200 | 18 | 15 | 3660 | 3260 | 2760 | 3710 | 2940 |
| GBM30.0-10000 | 7120 | 15.2 | 10 | 200 | 18 | 15 | 3720 | 3260 | 2760 | 3710 | 3200 | ||
| GBM30.0-11000 | 7520 | 16.4 | 11 | 200 | 18 | 15 | 3920 | 3280 | 2860 | 3890 | 3200 | ||
| GBM37.0-12000 | 37 | 44 | 9060 | 18.7 | 12 | 200 | 19 | 16 | 4030 | 3590 | 2960 | 3910 | 3500 |
| GBM37.0-13000 | 9560 | 20 | 13 | 200 | 19 | 16 | 4090 | 3620 | 3050 | 4010 | 3500 | ||
| GBM37.0-14000 | 10060 | 21.3 | 14 | 200 | 19 | 16 | 4190 | 3640 | 3120 | 4180 | 3500 | ||
| GBM45.0-15000 | 45 | 54 | 11080 | 23.1 | 15 | 220 | 19 | 16 | 4370 | 3720 | 3220 | 4220 | 3800 |
| GBM45.0-16000 | 11680 | 24.5 | 16 | 220 | 19 | 16 | 4470 | 4050 | 3310 | 4240 | 3800 | ||
| GBM45.0-18000 | 12820 | 27.2 | 18 | 220 | 19 | 16 | 4600 | 4120 | 3400 | 4390 | 4000 | ||
| GBM55.0-20000 | 55 | 66 | 15980 | 32 | 20 | 220 | 21 | 19 | 4850 | 4190 | 3480 | 4670 | 4000 |
| GBM55.0-23000 | 16860 | .35.3 | 23 | 220 | 21 | 19 | 4850 | 4430 | 3590 | 4860 | 4150 | ||
| GBM55.0-25000 | 17780 | 37.8 | 25 | 220 | 21 | 19 | 4850 | 4430 | 3590 | 4830 |
4500 |
||
